The Anti Stick feature, which is always on, prevents your electrode from sticking to your workpiece. When the machine detects sticking, the current will drop significantly, so the electrode can be removed.
The adjustable hot start is designed to help with striking an arc. The hot start temporarily boosts the output current at the start, making striking an arc, even with difficult electrodes, much easier. You get smoother arc starts, improving the quality of your weld.
Additional Features
Job Memory
The job memory function allows you to enter and store weld parameter settings. Weld parameters can be further adjusted and stored as required. A total of 10 jobs can be memorised and stored for recall.
Adjustable Arc Length
Get absolute precision on your settings. The adjustable arc length allows you to increase or decrease the preselected voltage while in synergic and pulse MIG modes.
Inductance Control
Take complete control of your arc with the inductance settings. By changing the frequency of your short circuit MIG welds with the Inductance controls, you can choose your preferred arc characteristics on every weld.
Burnback Adjustment
Stop your wire from ever fusing with your weld or your contact tips again. Tune your burnback control to suit how much wire you want to remain sticking out from your torch when you finish a weld.
Generator Compatible
Take it anywhere. Connect the machine to a generator and use it wherever, whenever you need it. We recommend 10kVA for this machine.
Lightweight & Portable
Weighing just 13.5kg, you can take this machine with you anywhere.
Specifications
Machine Specifications
Primary Input Voltage 240V Single-Phase
Open Circuit Voltage (OCV) 67.0
Open Circuit Voltage with VRD Active (V) 11.0
Minimum Generator (kVA) 10.0
Dimensions (LxWxH) 523 x 214 x 388mm
Suitable Materials
MIG: Mild Steel, Stainless Steel, Aluminium, Silicon Bronze
MMA: Mild Steel, Stainless Steel, Cast Iron
TIG: Mild Steel, Stainless Steel, Copper, Silicon Bronze, Titanium
MIG Specifications
MIG Current Range 30-185A
MIG Duty Cycle @ 40°C
10% @ 185A
60% @ 77A
100% @ 60A
MIG Wire Spool Sizes 1kg (D100) / 5kg (D200)
MIG Welding Thickness Range 1-10mm
Drive Roller Size 30/22
TIG Specifications
TIG Ignition Type DC High-Frequency TIG & DC Lift Arc
TIG Current Range 20-185A
TIG Duty Cycle @ 40°C
10% @ 185A
60% @ 77A
100% @ 60A
TIG Welding Thickness Range 1-6mm
MMA Specifications
MMA Current Range 20-180A
MMA Duty Cycle @ 40°C
10% @ 185A
60% @ 75A
100% @ 60A
MMA Electrode Range 2.5-4.0mm
MMA Welding Thickness Range 2-10mm
