STAFFORD AC/DC 320D
P/N SAC/DC320D
THE ALL STAFFORD AC/DC 320 PULSE IGBT INVERTER IS A PORTABLE INDUSTRIAL GRADE AC/DC TIG AND MMA WELDING MACHINE.
SUPERIOR TIG WELDING WITH AMPERAGE RANGE OF 5—320AMPS PROVIDES THE ABILITY TO WELD THIN SHEET METAL AND THE EXTRA AMPERAGE CAPACITY TO WELD THICKER METALS.
THE STAFFORD AC/DC 320 WELDS STAINLESS STEEL, ALLOY STEEL, AND OTHER NON-FERROUS METALS WITH DC FUNCTION AND WELDS ALUMINUM OR ALLOY ALUMINUM WITH AC FUNCTION.
FULLY DIGITAL CONTROLLED SETTING MAKE THIS MACHINE EASY TO SET FOR ALL YOUR APPLICATIONS.
OUR MACHINE COMES EVERYTHING STANDARD UNLIKE OUR COMPETITORS
- AC/DC 320D MACHINE
- 26V FINGER TIP CONTROL TIG TORCH WITH FLEX HEAD
- WATER COOLED TORCH
- TIG TORCH CONSUMABLE PACK
- 4M ARC LEAD
- 4M EARTH LEAD
- FOOT CONTROLLER
- ARGON REGULATOR
- GAS HOSE WITH QUICK RELEASE GAS FITTING
PRODUCT FEATURES
AC/DC FUNCTION
AC BALANCED CONTROL
FULLY ADJUSTABLE PULSING CONTROL
FULLY ADJUSTABLE DOWN SLOPE & POST FLOW
2T/4T TRIGGER FUNCTION
HF ARC STARTING
MMA FUNCTION
FOOT CONTROL
QUALITY FINGER TIP CONTROL 17V TIG TORCH
GERMAN MADE IGBT INVERTER COMPONENT
SPECIFICATION
Input Voltage (V) 415V
Frequency (Hz) 50/60
AC TIG : 10-320
DC TIG : 5-320
MMA : 20-250
Rated Duty Cycle (%)
60% @ 250amp
100% @ 190amp
Efficiency (%) 83
Output Voltage Adjustment (V) 10.2 - 22.8
Power Factor 0.9
Arc Starting HF
Pulse Frequency(Hz) 0.5-25
Pre-gas Flow Time(S) 0-10
Gas Post Flow Time(S) 1-25
Down Slope Time(S) 0-10
Clean Area Width(%) 30-70
Insulation Grade F
Housing Protection Grade IP21S
Weight (KGS) 25
Fully Compliant to AS 60974-1
3 YEAR WARRANTY
